MI200T – Spot Welder
MI200T – Spot Welder
Premium squeeze-type resistance spot welder with inverter head
The MI200T’s high-performance transformer pliers draw up to 40 percent less power than many cable pliers, further enhancing its energy savings and long-term cost-effectiveness. This high-efficiency design also means that the amperage service required for the MI200T is one of the lowest in the industry, typically requiring only a 40A service. In addition, the MI200T’s duty cycle is so high that the technician can operate the welder continuously without having to slow down to let the welder cool off. Liquid cooling to the tips is standard. The MI200T is specifically designed for high-strength steels such as Boron, USIBOR, TRIP, TWIP, and XIP. It has been quality tested and approved by many car manufacturers.
Description
- 20 feet of welding cable for increased reach
- C-pliers (multiple size arms available)
- Designed for all vehicle body repairs with high-strength steels
- Detects and adjusts welding parameters
- Flip lever locking system
- High-duty cycle
- LCD user interface
- Lightweight transformer pliers (uses 40% less power than standard cable plier welder)
- Provides instant feedback on weld quality
- TrueAutoMode™ features:
- Detects metal types and thicknesses
- Logs data for each repair
- Scans for the presence of adhesives and insulation
Specifications
- Ambient temperature: 41 to 113˚ F
- Clamp Weight: 22 lbs.
- Connection Cable Length: 19+’
- Dimensions H / W / D: 36.4″ / 25.6″ / 31.5″
- Electrode Force: 550 daN with 8 bars
- Frequency: 50/60 Hz
- Fuse: 40 Amp slow blowing
- Maximum welding current: 14,500 A DC (at 230V)
- Nominal power by 50%: ED 20kVA
- Power Supply: 208-240V (3 phase)
- Protective System: IP 21
- Supply Power: 14 kVA (80 kVA max)
- Weight without Accessories: Approx. 220 lbs.
More Information & Resources
Parts/Accessories:
</>
(Image Source: https://chieftechnology.com/product/mi200t-spot-welder/)
Chief® MI200T Spot Welder from Vehicle Service Group on Vimeo.
Additional Documents: MI200T Brochure, International Brochures
