TransSteel Pulse 3000 C Mig
TransSteel Pulse 3000 C Mig
STANDARD PACKAGE:
- 300A welding power source
- Integrated wire feeder
- MIG Torch, air-cooled, 60,15′
- Ground Cable, clamp, 13′
- Consumables, .035 – .045
- Flow meter with gas adaptor
- Pre-assembled & tested
Includes: 400i US Style MIG torch.
Features Multiprocess, Pulse, and Synchropulse
Description
General Data
| Mains voltage | 3 x 400V |
| Mains Frequency | 50-60Hz |
| Welding current min. | 3 A |
| Welding current max. | 320 A |
| Welding current / Duty cycle [10min/40°C] | 320A / 40% |
| Welding current / Duty cycle [10min/40°C] | 260A / 60% |
| Welding current / Duty cycle [10min/40°C] | 220A / 100% |
| Open-circuit voltage | 71 V |
| Degree of protection | IP23 |
| Dimension / length | 706 mm |
| Dimension / width | 300 mm |
| Dimension / height | 510 mm |
Technical Data
| Mains fuse | 35A |
