LT33A Air – Hydraulic Lifting Table From Rotary
LT33A Air – Hydraulic Lifting Table From Rotary
GET READY TO SAFELY SERVICE ELECTRIC VEHICLES
Rotary’s LT33A lift table is designed and built by the maker of the most trusted lifts in the vehicle service industry. Modeled to service batteries on hybrid and electric vehicles, boost your service options today.
Description
Experience the ultimate flexibility in lift positioning and ease of use with these patent-pending features. The LT33A single section scissor lift design has a wide, stable base to help technicians securely and efficiently remove, and install heavy vehicle components from electric battery packs, engines, and transmissions.
Specifications
- Standard 6” Casters
- Optional 8” Casters*
- Lift Table Capacity: 3,300 lbs.
- Maximum Rise Height: 67 3/8” | 69 3/8”
- Collapsed Height: 26 1/4” | 28 1/4”
- Overall Width: 36 1/4”
- Overall Length: 97 3/8”
- Deck Width: 31 7/8”
- Deck Length Closed: 73 5/8”
- Open: 81 5/8”
- First Locking Positions**: 32” | 34”
- Air Requirements: 90-120 PSI 6.2-8.3 bar
- Clearance: 4 3/4” | 6 3/4”
- Overall Weight:1,300 lbs.
More Information & Resources
Additional Documents: Brochure
